GRE Pipes

GRE Pipes

  • Salient Features
  • Technical Specifications
  • Quality Specifications

Salient Features

  • Long, Effective service life materials
  • Corrosion Resistance
  • No need for linings, coatings, cathodic protection, wraps or other forms of additional corrosion
  • Light in weight, Hence low transport costs
  • Eliminates need for expensive handling equipment
  • Standard length up to 12 meter, Hence fewer joints reduce installation time
  • Extremely smooth inner bore, Hence low friction loss in pipelines means less pumping energy needs and lower operating costs
  • High Resistance to Surge Pressure
  • Low Thermal Conductivity
  • UV Resistance
  • Better Hydraulic Efficiency
  • Low maintenance cost

Technical Specification

Our pipes, fittings and liners are ID based and cover a wide range of applications and sizes.

Design Standards

  • DN - Diameters from 25 mm to 3000 mm
  • Major Design Standards: API 15LR, ASTMD 2992, AWWA M45, ASTMD 2996, IS0 14692, ASME B 31.3

Class

  • PN - Pressure Classes 3, 6, 9, 12 & 15 Bar. Availability of higher pressure classes on request upto 70 Bar
  • SN - Stiffness Classes 62, 124, 248 & 496 kPa. Availability of higher stiffness classes on request

Size

L - Length from 2 mtrs to 12 mtrs


Material of Construction

  • Epoxy Resin
  • Fiberglass

Quality Specifications

  • As per AWWA Specifications: AWWA C 950
  • For High Pressure Applications: ASTM D 2996
  • For Hydrostatic Design Base: ASTM D 2992
  • For Oil & Petroleum Sector: API 15 LR up to 1000 PSI
